DeWalt DCPW550 - Maintenance; Repairs

ENGLISH
9
Repairs
The charger and battery pack are notserviceable. There are
no serviceable parts inside the charger or batterypack.

WARNING: To assure product SAFETY and RELIABILITY,
repairs, maintenance and adjustment (including brush
inspection and replacement, when applicable) should
be performed by a DeWALT factory service center or a
DeWALT authorized service center. Always use identical
replacementparts.
Accessories

WARNING: Since accessories, other than those offered by
DeWALT, have not been tested with this product, use of such
accessories with this tool could be hazardous. To reduce the
risk of injury, only DeWALT recommended accessories should
be used with thisproduct.
Recommended accessories for use with your tool are
available at extra cost from your local dealer or authorized
service center. If you need assistance in locating any
accessory, please contact DeWALT; call 1-800-4-DeWALT
(1-800-433-9258) or visit our website: www.dewalt.com.
Nozzle (Fig.A, F)
If the nozzle becomes clogged with foreign materials,
such as dirt, excessive pressure may develop. If the nozzle
becomes partially clogged or restricted, the pump pressure
will pulsate. Clean the nozzleimmediately.
1. Shut off the power cleaner
2
and turn off the
watersupply.
2. Pull trigger
6
on main handle
1
to relieve any
waterpressure.
3. Remove the nozzle from the spray wand
8
by pulling
the quick connect collar
9
toward the spraywand.
4. Unclog any debris from thenozzle.
Cleaning

WARNING: Blow dirt and dust out of all air vents with
clean, dry air at least once a week. To minimize the risk of eye
injury, always wear ANSI Z87.1approved eye protection when
performingthisprocedure.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non‑metallic parts of the tool. These
chemicals may weaken the plastic materials used in these
parts. Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any part
of the tool into aliquid.
MAINTENANCE

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/installing
attachments or accessories. An accidental start‑up can
causeinjury.
Shutdown (Fig.A)
1. To stop the power cleaner, release thetriggerand
remove thebattery .
2. Turn off water at thefaucet.
3. Discharge residual pressure by squeezing the trigger
6
until no more water comes out of the spray wand
8
.
4. Disconnect the garden hose from the water intake
3
and drainhose.
5. Remove garden hose from power cleaner by pulling back
the collar on the quick connect garden hose adapter and
removing it from the quick connectfilter.
Cleaning a Surface (Fig.J)

WARNING: Risk of injury from spray. Always engage the
trigger lock when gun is not in use. Failure to do so could
cause accidentalspraying.
1. To start the power cleaner, disengage the trigger
lock‑off
4
and squeeze the trigger
6
.
NOTE: The best angle for spraying water against a cleaning
surface is 45°. Spraying head on tends to cause dirt particles
to embed in the surface. When working on vertical surfaces,
it is best to apply detergent starting at the bottom and
working upwards which will prevent the detergent from
sliding down and causingstreaks.
2. To stop the power cleaner, release thetrigger.
NOTE: Excessive pump pressure may be the result of a
clogged nozzle or brass coupling. Always turn off the power
cleaner and remove the battery before attempting to
unclog a nozzle or brasscoupler.

WARNING: Never draw from water that contains
chemicals. Only draw from fresh watersources.
Storage
• Always completely empty water from the suction hose,
power cleaner, spray wand, nozzles, and soap bottle.
• Store in a dry, covered location above freezing
temperature. STOREINDOORS.
5. Run water from a faucet or garden hose through
thenozzle.
Soap Bottle (Fig.A)
1. To clean the soap bottle, shut off the power cleaner and
turn off the watersupply.
2. Pull trigger on gun handle to relieve any waterpressure.
3. Decouple the soap bottle
11
from the power cleaner
and unscrew the soap bottlenozzle.
4. To clean the soap bottle
11
, empty any remaining
detergent back into its container. Use water from a garden
hose to thoroughly rinse out the bottle. Empty the bottle
and allow it todry.
5. Reinstall soap bottle nozzle to the soapbottle.
Suction Hose (Fig.K)
1. To clean the suction hose
12
, shut off the
powercleaner.
2. Pull trigger switch to relieve any waterpressure.
3. Decouple the suction hose
12
from the powercleaner.
4. To clean the suction hose, use water from a garden hose
to thoroughly rinse out the suction hose and allow it todry.
Suction Hose Filter (Fig.K)
• Turn the filter
18
on the end of the suction hose
12
counterclockwise and remove. Remove the strainer from
inside of the filter. Rinse all of the parts with clean water
andreassemble.
Quick Connect Filter (Fig.A, L)
1. Pull back the collar on the quick connect hose
connector
13
and remove the garden or suction hose from
the quick connect filter
7
.
2. Remove the quick connect filter from the powercleaner.
3. Inside the quick connect filter
7
is a screen filter
19
.
Remove the screen filter and rinse with clean water
andreassemble.
