9
ENGLISH
Proper Hand Position (Fig.F)
WARNING: To reduce the risk of serious personal
injury, ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the hand
grip
5
, with the other hand on the main handle
8
.
Installing and Removing the Battery Pack
(Fig.E)
WARNING: Ensure the tool/appliance is in the off
position before inserting the batterypack.
NOTE: For best results, make sure your battery pack is
fullycharged.
1. To install the battery pack
7
into the tool handle,
align the battery pack with the rails inside the tool’s
handle and slide it into the handle until the battery
pack is firmly seated in the tool and ensure that it does
notdisengage.
2. To remove the battery pack from the tool, press the
release button
8
and firmly pull the battery pack out of
the tool handle. Insert it into the charger as described in
the charger section of thismanual.
OPERATION
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can causeinjury.
WARNING: Cut hazard. Blade breakage may occur
if the blade does not extend past the shoe and the
thickness of the workpiece during the cut. Increased
risk of personal injury, as well as damage to the shoe
and workpiece may result.
WARNING: Only sharp saw blades in perfect working
condition should be used; cracked or bent saw blades
should be discarded and replaced atonce.
Blade Installation and Removal (Fig. D)
To Install a Blade
1. Point tool away from body.
2. Use the tab on the blade clamp collar
3
, rotate open
the collar to its full open position.
3. Insert blade
10
fully into blade clampcollar.
NOTE: Blade can be installed with the teeth facing up to
assist in Flush Cutting.
4. Release blade clamp collar and gently tug on the blade to
ensure blade is clampedsecurely.
ASSEMBLY AND ADJUSTMENTS
WARNING:
To reduce the risk of serious personal
injury, turn unit off and
remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can causeinjury.
Wall Mounting
Some DeWALT chargers are designed to be wall mountable
or to sit upright on a table or work surface. If wall mounting,
locate the charger within reach of an electrical outlet,
and away from a corner or other obstructions which may
impede air flow. Use the back of the charger as a template
for the location of the mounting screws on the wall. Mount
the charger securely using drywall screws (purchased
separately) at least 1” (25.4mm) long, with a screw head
diameter of 0.28–0.35” (7–9mm), screwed into wood to an
optimal depth leaving approximately 7/32” (5.5 mm) of the
screw exposed. Align the slots on the back of the charger
with the exposed screws and fully engage them in theslots.
SAVE THESE INSTRUCTIONS FOR
FUTURE USE
To Remove a Blade (Fig. D)
WARNING: Burn hazard. Do not touch the the blade
immediately after use. Contact with the blade may
result in personalinjury.
1. Rotate open blade clamp collar
3
to its full
openposition.
2. Removeblade.
To Remove a Broken Blade
If the blade breaks so that the broken piece is caught
inside the clamp, take the following steps to remove the
remainder of the blade from the saw.
1. Remove battery.
2. Hold the blade clamp collar open. Face the clamp
opening down and shake the saw until the broken
blade falls out.
b. Check to see if receptacle is connected to a light
switch which turns power off when you turn out
thelights;
c. If charging problems persist, take the tool, battery
pack and charger to your local servicecenter.
4. You may charge a partially used pack whenever you
desire with no adverse effect on the batterypack.
Charger Cleaning Instructions
WARNING:Shock hazard. Disconnectthe charger
from the AC outlet before cleaning. Dirt and grease
may be removed from the exterior of the charger using
a cloth or soft non‑metallic brush. Do not use water or
any cleaningsolutions.
Variable Speed Trigger Switch (Fig.A,G)
Lock-Off Button and Trigger Switch
Your saw is equipped with a lock-off button
2
.
To lock the trigger switch, press the lock-off button on
the left. Always lock the trigger switch
1
when carrying or
storing the tool to eliminate unintentionalstarting.
To unlock the trigger switch, press the lock-off button
on the right. Pull the trigger switch to turn the motor ON.
Releasing the trigger switch turns the motorOFF.
