DeWalt DCS570 Original Instructions

12
ENGLISH
Battery Type
The DCS570 operates on a 18 volt batterypack.
These battery packs may be used: DCB181, DCB182, DCB183,
DCB183B, DCB184, DCB184B, DCB185, DCB187, DCB546,
DCB547. Refer to Technical Data for moreinformation.
Package Contents
The package contains:
1 Circular saw
1 Circular saw blade
1 Blade wrench
1 Parallel fence
1 Dust extraction port
1 Charger (C, D, L, M, P, S, T, X models)
1 Li-Ion battery pack (C1, D1, L1, M1, P1, S1, T1, X1 models)
2 Li-Ion battery packs (C2, D2, L2, M2, P2, S2, T2, X2 models)
3 Li-Ion battery packs (C3, D3, L3, M3, P3, S3, T3, X3 models)
1 Instruction manual
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
Wear earprotection.
Wear eyeprotection.
Visible radiation. Do not stare intolight.
Date Code Position (Fig. A)
The date code
19
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2017 XX XX
Year of Manufacture
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Trigger switch lock-off button
2
Trigger switch
3
Battery pack
4
Depth adjustment lever (Fig.E)
5
Base plate
6
Lower blade guard retracting lever
7
Lower blade guard
8
Blade clamping screw
9
Kerf indicator
10
Bevel adjustment lever
11
Blade lock button
12
Auxiliary handle
13
Battery release button
14
Blade wrench (Fig.E)
15
Worklight
Intended Use
These heavy-duty circular saws are designed for professional
wood cutting applications. Do not cut metal, plastic, concrete,
masonry or fiber cement materials. DO NOT use water feed
attachments with this saw. DO NOT use abrasive wheels or
blades. DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
These heavy-duty saws are professional powertools.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.

WARNING: Use only
DeWALT
battery packs andchargers.
Inserting and Removing the Battery Pack
from the Tool (Fig. A)
NOTE: Make sure your battery pack
3
is fullycharged.
To Install the Battery Pack into the Tool
Handle
1. Align the battery pack
3
with the rails inside the tool’s
handle (Fig. A).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the release button
13
and firmly pull the battery pack
out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.

DeWalt DCS570 Specifications

General

Max Speed	5500 RPM
Depth of Cut at 45 degrees	1-5/8 inches
Weight	7.5 lbs
Electric Brake	Yes
Dust Port	Yes
Blade Diameter	7-1/4 inches
Bevel Capacity	57 degrees
Depth of Cut at 90 degrees	2-9/16 in
Battery Type	20V MAX Lithium-Ion
