Bevel Angle Adjustment (Fig. A, G)
The bevel angle adjustment mechanism can be adjusted
between 0° and 57°.
To achieve better accuracy in cutting, use the fine adjustment
markings located on the pivot bracket
21
.
1. Raise the bevel adjustment lever
10
toloosen.
2. Tilt the base plate to the desired angle by aligning the fine
bevel pointer
22
with the desired angle mark on the pivot
bracket
21
.
3. Lower the bevel adjustment lever toretighten.
Bevel Detent (Fig. A, G)
The DCS570 is equipped with a bevel detent feature. As you
tilt the base plate
5
you will hear a click and feel the base
plate stop at both 22.5 and 45 degrees. If either of these is the
desired angle, retighten the lever
10
by lowering it. If you
desire another angle, continue tilting the base plate until the
coarse bevel pointer
23
or the fine pointer
22
aligns with the
desiredmark.
Cut Length Indicator (Fig. A)
The markings on the side of the base plate
5
show the length
of the slot being cut into the material at the full depth of the cut.
The markings are in increments of 5mm.
Kerf Indicator (Fig. I)
The front of the saw base plate has a kerf indicator
9
for vertical
and bevel cutting. This indicator enables you to guide the saw
along cutting lines penciled on the material being cut. The kerf
indicator lines up with the left (outer) side of the saw blade,
which makes the slot or “kerf” cut by the moving blade fall to
the right of the indicator. Guide along the penciled cutting line
so that the kerf falls into the waste or surplus material.
Mounting and Adjusting the Parallel Fence
(Fig. N)
The parallel fence
28
is used for cutting parallel to the edge of
theworkpiece.
Mounting
1. Slacken the parallel fence adjustment knob
27
to allow the
parallel fence topass.
2. Insert the parallel fence
28
in the base plate asshown.
3. Tighten the parallel fence adjustment knob
27
.
Adjusting
1. Slacken the fence adjustment knob
27
and set the parallel
fence
28
to the desired width. The adjustment can be read
on the parallel fencescale.
2. Tighten the fence adjustment knob
27
Mounting the Dust Extraction Port
(Fig. A, P)
Your circular saw is supplied with a dust extractionport.
To Install the Dust Extraction Port
1. Fully loosen depth adjustment lever
4
.
2. Place the base plate
5
in the lowestposition.
3. Align the left half of the dust extraction port
29
over upper
blade guard
7
as shown. Be sure to insert the tab into the
casting notch on the tool. When installed correctly, it will
snap fully over the original depth of cutpointer.
4. Align the right-hand piece
30
with theleft.
5. Insert screws and tightensecurely.
Prior to Operation
• Make sure the guards have been mounted correctly. The
saw blade guard must be in closedposition.
• Make sure the saw blade rotates in the direction of the
arrow on theblade.
• Do not use excessively worn sawblades.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
Proper Hand Position (Fig. J)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the main handle
26
, with the other hand on the auxiliary handle
12
.
LED Worklight (Fig. A)
The LED worklight
15
is activated when the trigger switch is
depressed. When the trigger is released, the worklight will stay
illuminated for up to 20seconds.
NOTE: The worklight is for lighting the immediate work surface
and is not intended to be used as aflashlight.
Switching On and Off (Fig. B)
For safety reasons the trigger switch
2
of your tool is equipped
with a lock-off button
1
.
Press the lock-off button to unlock thetool.
To run the tool, press the trigger switch
2
. As soon as the
trigger switch is released, the lock-off switch is automatically
activated to prevent unintended starting of themachine.
NOTICE: Do not switch the tool ON or OFF when the saw
blade touches the workpiece or othermaterials.
Workpiece Support (Fig. J–M)
WARNING: To reduce the risk of serious personal
injury, support the work properly and hold the
saw firmly to prevent loss ofcontrol.
