DeWalt DCS570 Original Instructions

16
ENGLISH
Figures J and K show proper sawing position. Figures L and M
show an unsafe condition. Hands should be kept away from
cutting area, and power cord is positioned clear of the cutting
area so that it will not get caught or hung up on thework.
To avoid kickback, ALWAYS support board or panel NEAR the
cut, (Fig. J and K). DON’T support board or panel away from the
cut (Fig.L and M). When operating the saw, keep the cord away
from the cutting area and prevent it from becoming hung up on
the workpiece.
ALWAYS DISCONNECT SAW BEFORE MAKING ANY ADJUST-
MENTS! Place the work with its “good” side—the one on which
appearance is most important—down. The saw cuts upward,
so any splintering will be on the work face that is up when you
sawit.
Cutting (Fig. J)

WARNING: Never attempt to use this tool by resting it
upside down on a work surface and bringing the material
to the tool. Always securely clamp the workpiece and
bring the tool to the workpiece, securely holding the tool
with two hands as shown in FigureJ.
Place the wider portion of the saw base plate on that part of
the work piece which is solidly supported, not on the section
that will fall off when the cut is made. As examples, FigureJ
illustrates the RIGHT way to cut off the end of a board. Always
clamp work. Don’t try to hold short pieces by hand! Remember
to support cantilevered and overhanging material. Use caution
when sawing material frombelow.
Be sure saw is up to full speed before blade contacts material
to be cut. Starting saw with blade against material to be cut
or pushed forward into kerf can result in kickback. Push the
saw forward at a speed which allows the blade to cut without
laboring. Hardness and toughness can vary even in the same
piece of material, and knotty or damp sections can put a heavy
load on the saw. When this happens, push the saw more slowly,
but hard enough to keep working without much decrease
in speed. Forcing the saw can cause rough cuts, inaccuracy,
kickback, and over-heating of the motor. Should your cut begin
to go off the line, don’t try to force it back on. Release the switch
and allow blade to come to a complete stop. Then you can
withdraw the saw, sight anew, and start a new cut slightly inside
the wrong one. In any event, withdraw the saw if you must shift
the cut. Forcing a correction inside the cut can stall the saw and
lead tokickback.
IF SAW STALLS, RELEASE THE TRIGGER AND BACK THE SAW
UNTIL IT IS LOOSE. BE SURE BLADE IS STRAIGHT IN THE CUT AND
CLEAR OF THE CUTTING EDGE BEFORERESTARTING.
As you finish a cut, release the trigger and allow the blade to
stop before lifting the saw from the work. As you lift the saw,
the spring-tensioned telescoping guard will automatically close
under the blade. Remember the blade is exposed until this
occurs. Never reach under the work for any reason. When you
have to retract the telescoping guard manually (as is necessary
for starting pocket cuts) always use the retractinglever.
NOTE: When cutting thin strips, be careful to ensure that small
cutoff pieces don’t hang up on inside of lowerguard.
Pocket Cutting (Fig. O)

WARNING: Never tie the blade guard in a raised position.
Never move the saw backwards when pocket cutting. This
may cause the unit to raise up off the work surface which
could causeinjury.
A pocket cut is one that is made in a floor, wall or other
flatsurface.
1. Adjust the saw base plate so the blade cuts at desireddepth.
2. Tilt the saw forward and rest front of the base plate on
material to becut.
3. Using the lower guard lever, retract lower blade guard to an
upward position. Lower rear of base plate until blade teeth
almost touch cuttingline.
4. Release the blade guard (its contact with the work will keep
it in position to open freely as you start the cut). Remove
hand from guard lever and firmly grip auxiliary handle
12
,
as shown in FigureO. Position your body and arm to allow
you to resist kickback if itoccurs.
5. Make sure blade is not in contact with cutting surface before
startingsaw.
6. Start the motor and gradually lower the saw until its base
plate rests flat on the material to be cut. Advance saw along
the cutting line until cut iscompleted.
7. Release trigger and allow blade to stop completely before
withdrawing the blade from thematerial.
8. When starting each new cut, repeat asabove.
Dust Extraction (Fig. Q)

WARNING: Risk of dust inhalation. To reduce the risk of
personal injury, ALWAYS wear an approved dustmask.
A dust extraction port
30
is supplied with yourtool.
The Dust Extraction Adaptor
31
allows you to connect the tool
to an external dust extractor, either using the AirLock™ system
(DWV9000-XJ), or a standard 35mm dust extractorfitment.

WARNING: ALWAYS use a vacuum extractor designed
in compliance with the applicable directives regarding
dust emission when sawing wood. Vacuum hoses of most
common vacuum cleaners will fit directly into the dust
extractionoutlet.
MAINTENANCE
Your
DeWALT
power tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regularcleaning.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
The charger and battery pack are notserviceable.

DeWalt DCS570 Specifications

General

Max Speed	5500 RPM
Depth of Cut at 45 degrees	1-5/8 inches
Weight	7.5 lbs
Electric Brake	Yes
Dust Port	Yes
Blade Diameter	7-1/4 inches
Bevel Capacity	57 degrees
Depth of Cut at 90 degrees	2-9/16 in
Battery Type	20V MAX Lithium-Ion
