DeWalt DCS577 Instruction Manual

ENGLISH
1
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.

(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.

WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
If you have any questions or comments about this or
any
DeWALT
tool, call us toll free at:
1-800-4-
DeWALT
(1-800-433-9258).
1
Trigger switch lock off
button
2
Trigger switch
3
Depth adjustment
locking lever
4
Lower blade guard
retracting lever
5
Foot plate
6
Lower blade guard
7
0˚ Kerf indicator
8
45˚ Kerf indicator
9
Bevel adjustment lever
10
Angle quadrant
11
Spindle lock button
12
Main handle
13
Auxiliary handle
14
Battery release button
15
Battery
16
Coarse adjustment
17
Fine adjustment
18
Kerf indicators
19
Blade clamping screw
Fig. A
15
1
2
14
3
13
4
19
11
6
5
8
7
9
10
16
17
12
18
18
