DeWalt DCS691X2 User Manual

10
ENGLISH
x
Discard the battery pack with due care for
theenvironment.
y
Charge battery packs only with designated DeWALT
chargers. Charging battery packs other than the
designated DeWALT batteries with a DeWALT
charger may make them burst or lead to other
dangeroussituations.
z
Do not incinerate the batterypack.
B
USE (without transport cap). Example: Wh rating
indicates 108Wh (1battery with 108Wh).
A
TRANSPORT (with built‑in transport cap). Example: Wh
rating indicates 3x 36Wh (3batteries of 36Wh).
Battery Type
The following tools operate on a 54 volt (60V Max) battery pack:
DCS691
These battery packs may be used: , DCB546, DCB547, DCB548,
DCB549, DCB606, DCB609, DCB612, DCB615. Refer to Technical
Data for moreinformation.
Package Contents
The package contains:
1 Cut off tool
1 Diamond blade
1 12.7mm wrench
1 Battery charger (X2 version only)
2 Li‑Ion battery packs (X2 version only)
1 Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by DeWALT is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
Wear earprotection.
Wear eyeprotection.
Risk of dustemission.
Higher risk of kickback! Do not use the upper quarter
of the wheel forcutting.
Date Code Position (Fig.A)
The date code
14
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2022XX XX
Year and Week of Manufacture
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Main handle
2
Trigger switch
3
Lock‑off button
4
Battery door
5
12.7 mm wrench
6
LED light
7
Front handle
8
Guard
9
Arbor screw
10
Spindle lock button
11
Guard rotation lever
12
Shoe
13
Water valve
14
Date code
15
Water inlet
Intended Use
Your cut‑off tool is designed for professional cutting
applications. Only use wet cut method when cutting concrete.
DO NOT use in the presence of flammable liquids orgases.
Your cut‑off tool is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
• DO NOT cut concrete without connecting the water
supplysystem.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.

WARNING: Use only DeWALT battery packs andchargers.
