DeWalt DCS691X2 User Manual

ENGLISH
3
English (original instructions)
CUT-OFF TOOL
DCS691
a
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.

DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.

WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.

CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.

Denotes risk of electricshock.

Denotes risk offire.
GENERAL POWER TOOL SAFETY WARNINGS

WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or seriousinjury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTUREREFERENCE
The term “power tool” in the warnings refers to your
mains‑operated (corded) power tool or battery‑operated (cordless)
powertool.
Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust orfumes.
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough product development and innovation make DeWALT one of the most
reliable partners for professional power toolusers.
Technical Data
DCS691
Voltage V
DC
54 (60 Max)
Battery type Li-Ion
Wheel diameter mm 230
Wheel bore mm 22.2
No load/rated speed min
-1
6600
Wheel perimeter thickness (max.)
Metal mm 3.6
Resin-bonded mm 3.6
Thread size M8
Water quick connector mm 12.5
Weight (without battery pack) kg 5.7
Batteries Chargers / Charge Times (Minutes)
Cat# V
DC
Ah Weight(kg)
DCB104 DCB107 DCB112 DCB115
DCB117
DCB1112
DCB118 DCB132
DCB546/DCB606 18/54 (20/60 Max) 6.0/2.0 1.08 60 270 170 90 40 60 90
DCB547/DCB609 18/54 (20/60 Max) 9.0/3.0 1.46 75* 420 270 135* 60 75* 135*
DCB548/DCB612 18/54 (20/60 Max) 12.0/4.0 1.46 120 540 350 180 80 120 180
DCB549/DCB615 18/54 (20/60 Max) 15.0/5.0 2.12 125 730 450 230 90 125 230
*Date code 201811475B or later
