23 en - 8
ENGLISH
Using templates
• Position the ball bearing over the cutter, making sure the centre of the
two are in line.
• Prepare a template. The difference between bearing and cutter
diameter corresponds to the difference between workpiece and
template dimensions.
• Secure the template to the workpiece using double-sided tape.
• With the router off, move your workpiece in the desired manner,
to make sure that all points can be moulded as required.
For the correct position of the ball bearing (91), refer to fig. M3:
• A Edge moulding with bearing off-centre.
• B Trimming facing material flush to edge of workpiece with a
trimming cutter.
• C Edge moulding following template contour.
Mounting the dust extraction set (DE2005) (fig. A2 - A3)
The dust extraction set has two hoses: one is to be connected to the
power tool and the other one to the dust spout on the combi-table
(DE3000: on the saw blade guard [25]; DE2000: on the router fence [29]).
• Slide the dust extraction hose over the dust spout (24 or 33).
Consult your dealer for further information on the appropriate accessories.
Maintenance
Your attachment has been designed to operate over a long period of time
with a minimum of maintenance. Continuous satisfactory operation
depends upon proper tool care and regular cleaning.
• Replace the cutting insert when worn out.
Cleaning
Keep the grooves clear of saw dust. Regularly clean the combi-table with
a soft cloth.
Unwanted products and the environment
Take your attachment to an authorized DEWALT repair agent where it will
be disposed of in an environmentally safe way.
GUARANTEE
• 30 DAY NO RISK SATISFACTION GUARANTEE •
If you are not completely satisfied with the performance of your
DEWALT tool, simply return it within 30 days, complete as purchased,
to the point of purchase, for a full refund or exchange. Proof of
purchase must be produced.
• ONE YEAR FREE SERVICE CONTRACT •
If you need maintenance or service for your DEWALT tool, in the
12 months following purchase, it will be undertaken free of charge at
an authorized DEWALT repair agent. Proof of purchase must be
produced. Includes labour and spare parts for the attachments.
Excludes accessories.
• ONE YEAR FULL WARRANTY •
If your DEWALT product becomes defective due to faulty materials or
workmanship within 12 months from the date of purchase,
we guarantee to replace all defective parts free of charge or, at our
discretion, replace the unit free of charge provided that:
• The product has not been misused.
• Repairs have not been attempted by unauthorized persons.
• Proof of purchase date is produced.
This guarantee is offered as an extra benefit and is additional to
consumers statutory rights.
For the location of your nearest authorized DEWALT repair agent,
please use the appropriate telephone number on the back of this
manual. Alternatively, a list of authorized DEWALT repair agents and full
details on our after-sales service are available on the Internet at
www.2helpU.com.
