ENGLISH
1
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.

(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.

WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.

WARNING: To reduce the risk of injury, read the
instructionmanual.
1
Trigger switch
2
Lock on button
3
Forward/ reverse button
4
Main handle
5
Side handle
6
Chuck
7
Hammer/Drill selector switch
8
Depth Rod
Fig. A
1
2
5
6
4
3
7
8

DeWalt DW505 Specifications

General

Reverse	-
Drilling	No
Chuck type	Key
Product color	Black, Yellow
Hammer drilling	Yes
Number of gears	2
Input power	800 W
Power source	AC
Rated speed (max)	3000 RPM
Rated speed (min)	1270 RPM
Drilling diameter in steel (max)	13 mm
Drilling diameter in stone (max)	19 mm

Weight and Dimensions

Weight	2177 g
