DeWalt DWV905MQS - Filter Care; Connecting to Power Tools; Pairing with Wireless Tool Control

30
ENGLISH
2. Turn on/off tool control switch
15
to the ACTIVATION
position . This allows the vacuum to be turned on and off
automatically by the powertool. The minimum power of
the tool must be larger than 250watts for the Vacuum to be
controlled via the socket?
NOTE: The vacuum cleaner starts automatically within 0.5
seconds and continues to run for 7 seconds after the power
tool has been turnedoff. Afterrun can vary when used with
a powergenerator.
3. To switch back to manual mode, turn the on/off tool control
switch
15
to the ON position
 
). In manual mode the tool
and the vacuum are turned on and off independent of
eachother.
4. Your DeWALT construction dust extractor is fitted with the
DeWALT AirLock connection system. The AirLock allows for
a fast, secure connection between the suction hose
7
and
power tool. The AirLock connector
25
connects directly to
DeWALT compatable tools or through the use of an AirLock
adapter (available from your local DeWALT supplier). Refer
to the Accessories section for detail on available adapters.
NOTE: If using an adapter ensure it is firmly attached to the
tool outlet before following the stepsbelow.
a. Ensure the collar on the AirLock connector is in the
unlock position. Align notches
26
on collar and AirLock
connector as shown for unlock and lockpositions.
b. Push the AirLock connector onto the adapter
connectorpoint.
c. Rotate the collar to the locked position.
NOTE: The ball bearings inside collar lock into slot and
secure the connection.The power tool is now securely
connected to the dustextractor.
Hose Diameter Adjustment (Fig.E)
Adjust the three-position switch
16
to the correct hose (or
tube) inside diameter size (32mm or 20mm) or accessory
diameter referring to the largest section. The chosen diameter
of the adjustment control must be equal or bigger as the largest
diameter of the used hose/tube/ accessories. The hose supplied
is 32mm inside diameter. An acoustic alarm will sound if the
flow rate falls below 20m/s. The system has a time delay to
reduce unintendedalarms.
NOTE: Set the hose diameter regulator only to the yellow
marked diameter ranges of the connected suctionhose.
If the alarm sounds when there is no apparent blockage:
1. Ensure that the adjustment control is set to the
correctdiameter.
2. If the flow rate adjustment is set below the maximum,
increase this level until sufficient flow through the hose
causes the alarm tostop.
3. If the alarm still continues to sound, remove hose and check
that it is clear. Remove and replace dust bag if full or blocked
and check filter condition and replace wherenecessary.
If the alarm continues to sound contact your local DeWALT
serviceagent.
NOTE: This setting also controls the level of suction. This
is very useful in applications where the vacuum creates
unacceptable levels of drag to the workpiece.
5. Follow the direction under Connecting to Power Tools to
connect to the power tool to beused.
NOTE: Refer to Pairing the Dust Extractor with a Tool using
Wireless Tool Control™ Mode to use the dust extractor with a
Wireless Tool Control™ equipped tool or remote.
Filter Care
Class H filters must not be cleaned manually. If the filter is
clogged, it must be disposedof.
The filters included with this vacuum are long life filters. To be
effective in minimizing dust recirculation, the filters MUST be
installed correctly and in goodcondition.

WARNING: Appropriate personal protective equipment
like dust mask and gloves should be used while handling
thefilters.

WARNING: Dispose of the used filter in accordance with
the legalregulations.
Connecting to Power Tools (Fig.C,D)

WARNING: Only use the outlet for purposes specified in
theinstructions.

WARNING: Before setting the switch to position "Tool
Control", make sure that the connected tool is switchedoff.

WARNING: The maximum load of the power tool shall
not exceed the rated maximum outlet power rating at the
socketoutlet.
NOTE: Some Brushless AC tools can start the Vacuum in auto
mode without turning on the power tool.
1. Plug the vacuum power cord into an appropriateoutlet.
Pairing the Dust Extractor with a Tool using
Wireless Tool Control™ Mode (Fig.A, M)

CAUTION: When the dust extractor is being controlled
with the remote or paired power tool it may start or stop
withoutwarning.

WARNING: Do not attach the remote strap to
movingparts.
To Pair with a DeWALT Remote or Wireless Tool
Control™ Tool
1. Turn the on/off tool control switch
15
to the position.
2. Press and hold the Wireless Tool Control™ pairing button
17
on
the extractor and pull the trigger on the Wireless Tool Control™-
equipped-tool, or press the remote button
28
on the Wireless
Tool Control™ remote
27
at the same time.
3. The LED above the Wireless Tool Control™ pairing button will
be steadily illuminated to indicate a successful pairing.

CAUTION: Do not activate the Wireless Tool Control at the
Tool if the dust extractor hose is not connected to the dust
extraction port of the tool.
NOTE: Only one transmitter can be paired to the DWV905 at a
time. If the unit is already paired the previous transmitter will be
overridden.
