LCD Screen (Fig. 3)
A. Battery Reconditioning
Icons
B. Battery Recondition
Indicator
C. High Temperature
Compensation Icon
D. Low Temperature
Compensation Icon
E. Digital Display (varies by
function)
F. Seconds/Voltage/Ampere/
Percentage Indicator
B
A
P
C D E F
G
H
I
A
JKLMO
N
G. USB Icon
H. Fault Icon
I. Alternator Good/Fault
Indicators
J. Alternator Icon
K. Pump Engine Icon
L. Overheat Alarm Icon
M. Alarm Icon
N. Clamp Icons
O. Reverse Polarity Icons
P. Battery Icon
Front Panel Components (Fig. 1)
A. LCD Screen
B. AC Pass-Through
C. Battery Charge Button
D. Battery Voltage Button
E. Engine Start Button
F. Battery Recondition Button
G Alternator Check Button
H. USB Power Button
I. USB Port
J. USB Power/Fault Indicator
JI
A
B
C E
H
D F
G
DXAEC801B_DXAEC801BCA_ManualENFRSP_073020.indd 8-9
10:30 AM
Back Panel Components (Fig. 2)
K. Padded Storage Tray
L. High-Speed Cooling Fan
M. Storage Tray
N. Negative Clamp (black)
O. Positive Clamp (red)
P. AC Power Cord (bottom of
apparatus)
Q. Fuse
R. Fuse Holder
N
K L M
O
P
Q R
