P3600
EN
2
INTRODUCTION
Thank you for purchasing the DEWALT P3600 low velocity powder actuated tool. This
tool will provide you with excellent performance provided the steps for proper operation
and maintenance are followed. Powder actuated fastening systems can provide a
cost effective method of attaching fixtures for light duty, static load conditions. The
systems provided by DEWALT consist of specially designed fasteners, installation
tools, and powder loads, which are designed to function in combination to provide
optimum performance. While powder actuated tools can provide one of the fastest and
economical means of fastening, they can also be dangerous if they are not operated
properly.
Prior to operating the P3600 tool, you must be properly trained in the operation and
maintenance of this tool and be issued a DEWALT Qualified Operator Card. When using
the tool, you must have this card in your possession. As part of the training process,
you should read and understand the contents of this instruction manual especially the
safety precautions.
Powder actuated tools may be operated only by properly trained operators as
described in ANSI Standard A 10.3, Safety Requirements for Powder Actuated
Fastening Systems. For complete tool operation details, contact your local DEWALT
Branch office or distributor for training.
Remember, safety begins with you! It is your primary responsibility when operating
this tool. Failure to follow the proper operating, maintenance, and safety procedures
can result in serious injury or death to yourself or bystanders. In addition to the training
provided, you should be familiar with any local, state, and federal regulations. If you
have any questions that are not covered in this manual, contact your local DEWALT
Branch office or distributor.
SIZE RANGE
Up to 3" (76mm) in length. 3/8" and 10mm Threaded Studs; .27 caliber powder loads.
TOOL DESCRIPTION
The P3600 is a powerful, heavy-duty, low velocity, semi-automatic .27 caliber tool, which
can be used to install 3/8”-16 and 10mm threaded studs. The P3600™ is designed for
applications where more power is needed. The tool utilizes a yellow (4), red (5) or
purple (6) .27 caliber strip.
TECHNICAL DATA
TOOL BODY MAX PIN LENGTH TOOL LENGTH
Precision Cast
Aluminum
Up to 3" (76mm)
Total Length
13-5/8"
(346mm)
LOAD TYPE TOOL WEIGHT POWER LEVEL
.27 Caliber in a
10 Load Strip
5 lbs. (2.25 kg) Yellow (4), Red (5),
Purple (6)
PIN TYPE
3/8" Threaded Studs, 10mm Threaded Studs
P3600 SELECTION GUIDE
CAT # DESCRIPTION CTN
52010-PWR P3600 Powder Tool (Deluxe Kit):
Tool, Spall Guard, 5mm Allen Wrench, 2 Annular Balls,
2 Sear Clips and Case
1
52579-PWR Nose Piece 1
52112-PWR Piston Stop 1
52106-PWR Piston Ring 1
52578-PWR Piston 1
