Dexter Laundry B Series Parts & Service Manual

33
Stages – Auto Dry
Auto Dry cycles are comprised of two stages – a heating stage and a cooldown stage.
Stage Parameters Options Notes
Heating
Temperature Preset Preset based on material type
Auto Dry Level 100% - 75% Auto Dry level and Moisture Remaining are
correlating numbers, giving you the option
to program towards a specic dryness level
(i.e., 95% dry) or to a moisture remaining
level (i.e., 5% moisture remaining). Both
numbers are shown to accommodate
dierent industry types.
Moisture
Remaining
0% - 25%
Cooldown
Temperature Not selectable Auto Dry cycles are set for no heat on
Cooldown. Any heat during cooldown could
impact the moisture content of a load
missing the desired target level.
Time 2 – 120 minutes Time in cooldown. Every cycle must include
a minimum two-minute cooldown to reduce
the risk of spontaneous combustion.
Stages – Time Dry
Time Dry cycles are typically encompassed of two stages – a heating stage and a cooldown
stage. However, time dry cycles also allow you to have multiple heating stages with dierent
temperatures. You can program up to 19 heating stages and 1 cooldown stage.
Stage Parameters Options Notes
Heating
Temperature No Heat
100
O
F – 190
O
F /
38
O
C – 91
O
C
Sets the desired temperature for the stage.
Temperature is programmable in 5
O
F / 3
O
C
increments.
Time 0 – 120 minutes Maximum cycle time is 120 minutes,
Cooldown
Temperature Not selectable
Time Dry cycles are set for no heat on
Cooldown.
Time
2 – 120 minutes Every cycle must include a two-minute
minimum cooldown to reduce the risk of
spontaneous combustion.
Add Stage Adds a heating stage. The stage that is
added is a direct copy of the last heating
stage and can be edited.
Part # 8533-112-001 7/21
