Dexter Laundry B Series Parts & Service Manual

61
CONTROL BOARD
Condition This error occurs when the Main Control Board cannot command the input and
outputs of the control system as required by the cycle programming.
Control
Action
When detected, the control turns o the motor and the heating relay. There is no
delay in the action once the criteria are met.
Exit The machine will not start and the Error Code will continue to be displayed until
the prompt is followed to Reset the Error Code and return the Machine to Idle
Mode. If the prompt to Reset is not available, power must be cycled to the ma-
chine to reset the error.
Customer
Action
GRAPHICS BOARD
Condition This error occurs when the Graphics Board cannot command the Main Control
board as required by the cycle programming.
Control
Action
When detected, the control turns o the motor and the heating relay. There is no
delay in the action once the criteria are met.
Exit The machine will not start and the Error Code will continue to be displayed until
the prompt is followed to Reset the Error Code and return the Machine to Idle
Mode. If the prompt to Reset is not available, power must be cycled to the ma-
chine to reset the error.
Customer
Action
MODEL JUMPER MISSING
Condition This error occurs when there is no connection to Ground (Pin 7) on the Model
Jumper Header.
Control
Action
When detected, the control turns o the motor and the heating relay. There is no
delay in the action once the criteria are met. The machine control checks for this
condition when power is cycled and before starting every machine cycle.
Exit The machine will not start and the Error Code will continue to be displayed until
the condition no longer exists and the prompt is followed to Reset the Error Code
and return the Machine to Idle Mode.
Customer
Action
Inspect and reseat Model Jumper harness at J6. Preform Soft reset holding down
both Reset button and Button 1 on the control board. release reset button con-
tinue to hold button 1 until display appears.
MODEL JUMPER CHANGED
Condition This error occurs when the jumper connections to Ground (Pin 7) on the Model
Jumper Header have changed since the last control check.
Control
Action
When detected, the control turns o the motor and the heating relay. There is no
delay in the action once the criteria are met. The machine control checks for this
condition when power is cycled and before starting every machine cycle.
Exit The machine will not start and the Error Code will continue to be displayed until
the condition no longer exists and the prompt is followed to Reset the Error Code
and return the Machine to Idle Mode.
Customer
Action
If someone has been doing repairs on the washer, check for the correct size drive.
Inspect and reseat Model Jumper harness at J6. Preform Soft reset holding down
both Reset button and Button 1 on the control board. release reset button con-
tinue to hold button 1 until display appears.
Part # 8533-112-001 7/21
