Dexter Laundry B Series Parts & Service Manual

68
Close Door
Condition This Error occures when the control detects that either the loading door or the
Lint compartment door circurcit is not closed
Control
Action
When detected, the control will not allow the cycle to start. the display “Close
Door”will stay present untill the circuit is closed
Exit When detected will not start until circuict is closed.
Customer
Action
Inspect Door switched and wiring. Inspect lint door paddle make sure fully en-
gauging lint door switch.
Control Board Error 11
Condition Model jumper not Selected or detected. Relay Board or control board.
Control
Action
Error will display and cycle will stop.
Exit The machine will not start and the Error Code will continue to be displayed until
the condition no longer exists and the prompt is followed to Reset the Error Code
and return the Machine to Idle Mode.
Customer
Action
Inspect Model Jumper on Relay board (P3) make sure connected and present.
Inspect I2C harness between control (Relay Exp.)and relay board (P1). Inspect for
12VO_SW LED make sure iluminated. If not test 12Vdc power supply, (must be
11.4 or above). Inspect harnesses if pinched of damaged (loading door and lint
switch).
Control Board Error 66
Condition Model jumper not Selected or detected. Relay Board or control board.
Control
Action
Error will display and cycle will stop.
Exit The machine will not start and the Error Code will continue to be displayed until
the condition no longer exists and the prompt is followed to Reset the Error Code
and return the Machine to Idle Mode.
Customer
Action
Inspect Model Jumper on Relay board (P3) make sure connected and present.
Inspect I2C harness between control (Relay Exp.)and relay board (P1). Inspect for
12VO_SW LED make sure iluminated. If not test 12Vdc power supply, (must be
11.4 or above). Inspect harnesses if pinched of damaged (loading door and lint
switch).
Control Board Error 68
Condition Model jumper not Selected or detected. Relay Board or control board.
Control
Action
Error will display and cycle will stop.
Exit The machine will not start and the Error Code will continue to be displayed until
the condition no longer exists and the prompt is followed to Reset the Error Code
and return the Machine to Idle Mode.
Customer
Action
Inspect Model Jumper on Relay board (P3) make sure connected and present.
Inspect I2C harness between control (Relay Exp.)and relay board (P1). Inspect for
12VO_SW LED make sure iluminated. If not test 12Vdc power supply, (must be
11.4 or above). Inspect harnesses if pinched of damaged (loading door and lint
switch).
Part # 8533-112-001 7/21
