8514-219-001 REV E PAGE 22
controller is pressed and released twice, consecutively, the cycle 1 program will revert to the
factory default settings.
If you press the START touch pad switch on the dryer controller, the controller display will
change from the number “5” to the number “45” and dry cycle 1 will begin.
PERMANENT DRYER CONTROLLER PROGRAMMING
The permanent programming mode will allow the change of the stored dry cycle settings in
the dryer controller until the operator physically changes them again. The factory default
settings can be restored in the dryer controller by pressing the default settings pushbutton on
the back (component) side of the dryer controller circuit board. It is labeled and located at the
lower middle side of the printed circuit board, as you face the component side of the board. It
must be pressed and held down for at least three seconds during power up.
To permanently change a dryer controller cycle, follow the procedure below. Things that
are displayed on the 4-digit numeric display will be in “quotation marks”. Touch pad switches
of the dryer controller that physically need to be pressed will be in CAPITAL AND BOLD
LETTERS.
If, at any time, you want to escape the permanent programming mode while changing the
settings, you can press the STOP touch pad switch on the dryer controller if the 4-digit
numeric display is not flashing. The SELECT/ENTER touch pad switch on the dryer controller
can be pressed and released to enter the flashing value shown on the 4-digit numeric display
and allow you to escape.
__________________________________________________________________
PROCEDURE
1) Make sure the dryer is not in a dry cycle. The 4-digit numeric display on the dryer
controller will show “LOAd” when the dryer is not in a dry cycle.
2) Press and release the PROG touch pad switch on the dryer controller.
3) Press and release the UP touch pad switch on the dryer controller. The programming
L.E.D. will illuminate and the 4-digit numeric display on the dryer controller will change to
“Prog”.
4) Press and release either the UP or DOWN touch pad switch on the dryer controller to
choose the dry cycle you want to change (dry cycle 1 through 5). The dry cycle L.E.D. will
illuminate to indicate which dry cycle you are choosing. If you press and hold down either
the UP or DOWN touch pad switch, the controller will sequence through the five dry
cycles.
5) Press and release the SELECT/ENTER touch pad switch on the dryer controller when you
have chosen the dry cycle you want to change. After you press the SELECT/ENTER
touch pad switch, the dry time L.E.D. will illuminate, the dry cycle L.E.D. and the
programming L.E.D. will remain illuminated, and the total dry time will be displayed on the
4-digit numeric display.
