26
27
2. Remove the motor cover from
the top.
3. Remove the damaged motor.
4. Install and compact the new motor, connect the new motor's connector
to the circuit board's connector.
5. Install the motor cover. 6. Install the lamp cover and lock
the covers with screw.
How to replace the gear
Warning: since the gear will be in heavy loss after long time flying,
consumers should replace the gear in time.
1. Loosen the propeller screw and
remove the propeller.
2. Loosen the lamp cover screw
and remove the lamp cover.
3. Remove the gear and steel shaft. 4. Press the gear and take it off.
