Hardware Installation
Power-on Select
JP6 is used to select the method of powering on the system. If you
want the system to power-on whenever AC power comes in, set
JP6 pins 2 and 3 to On. If you want to use the power button, set
pins 1 and 2 to On.

JP6
2-3 On:
Power-on via
AC power
1-2 On:
Power-on via
power button
(default)
1
3
2
1
3
2
