Hardware Installation
Connecting the Parallel Port Cable
Your parallel port may be mounted on a card-edge bracket. Install
the card-edge bracket to an available slot at the rear of the system
chassis then insert the cable connector to J25. Make sure the color-
ed stripe on the ribbon cable is aligned with pin 1 of J25.
BIOS Setting
Configure the parallel port in the Integrated Peripherals submenu
(“Super IO Device” section) of the BIOS. Refer to chapter 3 for
more information.
