COM Express Connectors
The COM Express connectors are used to interface the CH960-CM246/QM370/HM370 COM
Express board to a carrier board. Connect the COM Express connectors (located on the solder
side of the board) to the COM Express connectors on the carrier board.
Refer to the “Installing CH960-CM246/QM370/HM370 onto a Carrier Board” section for more
information.
COM Express Connectors
Refer to the following page for the pin functions of these connectors.
