Chapter 1 - Introduction
Specifications
Chapter 1
AUDIO Interface HD Audio
ETHERNET Controller CH960-CM246/QM370:
1 x Intel
®
I219LM with iAMT12.0 PCIe (10/100/1000Mbps)
CH960-HM370:
1 x Intel
®
I219LM PCIe (10/100/1000Mbps)
I/O USB 4 x USB 3.1
8 x USB 2.0
SATA CH960-CM246/QM370:
4 x SATA 3.0 (up to 6Gb/s)
RAID 0/1/5/10
CH960-HM370:
4 x SATA 3.0 (up to 6Gb/s)
DIO 1 x 8-bit DIO (Default 4 inputs and 4 outputs)
WATCHDOG
TIMER
Output &
Interval
System Reset, Programmable via Software from 1 to 255 Seconds
SECURITY TPM Available upon request
POWER Type 12V, 5VSB, VCC_RTC (ATX mode)
12V, VCC_RTC (AT mode)
OS SUPPORT Windows: Windows 10 IoT Enterprise 64-bit
Linux: Ubuntu 18.04
ENVIRONMENT Temperature Operating: 0 to 60°C or -40 to 85°C (with heat spreader)
Storage: -40 to 85°C
Humidity Operating: 5 to 90% RH
Storage: 5 to 90% RH
MECHANICAL Dimensions COM Express
®
Basic
95mm (3.74") x 125mm (4.9")
Compliance PICMG COM Express
®
R2.1, Type 6
SYSTEM Processor CH960-CM246/QM370:
8th Generation Intel
®
Core™ Processors, BGA 1440
Intel
®
Xeon
®
E-2176M Processor, 6 Cores, 12M Cache, 2.7GHz (4.4GHz), 45W
Intel
®
Core™ i7-8850H Processor, 6 Cores, 12M Cache, 2.6GHz (4.3GHz), 45W
Intel
®
Core™ i5-8400H Processor, 4 Cores, 8M Cache, 2.5GHz (4.2GHz), 45W
CH960-HM370:
8th Generation Intel
®
Core™ Processors, BGA 1440
Intel
®
Core™ i5-8400H Processor, 4 Cores, 8M Cache, 2.5GHz (4.2GHz), 45W
Chipset Intel
®
CM246/QM370/HM370 Chipset
Memory CH960-CM246/QM370:
Two 260-pin SODIMM up to 32GB
Dual Channel DDR4 2666MHz (ECC Support with CM246)
CH960-HM370:
Two 260-pin SODIMM up to 32GB
Dual Channel DDR4 2666MHz
BIOS AMI SPI 128Mbit
GRAPHICS Controller Intel
®
HD Graphics
Feature OpenGL up to 4.5, DirectX 11, OpenCL 2.1
HW Decode: HEVC/H.265, H.264, M/JPEG, MPEG2, VC1/WMV9, VP8 (8-bit), VP9 (10-bit)
HW Encode: HEVC/H.265, M/JPEG, MPEG2, VP8
Display 1 x VGA/DDI (DDI available upon request)
1 x LVDS/eDP (eDP available upon request)
2 x DDI (HDMI/DVI/DP++)
VGA: resolution up to 1920x1200 @ 60Hz
LVDS: dual channel 24-bit, resolution up to 1920x1200 @ 60Hz
HDMI: resolution up to 4096x2160 @ 30Hz 24bpp
DVI: resolution up to 1920x1200 @ 60Hz
DP++/eDP: resolution up to 4096x2304 @ 60Hz
Triple
Displays
VGA + LVDS + DDI or VGA + DDI1 + DDI2
eDP + 2 DDI (available upon request)
EXPANSION Interface 1 x PCIe x16 or 2 x PCIe x8 (Gen 3)
8 x PCIe x1 or 2 x PCIe x4 or 4 x PCIe x2 (Gen 3)
1 x LPC
1 x I²C
1 x SMBus
2 x UART (TX/RX)
