www.dfi .comChapter 3 Hardware Installation
27
Chapter 3
CPU fan
Standby Power LED
Standby Power LED
Standby
Power LED
This LED will light when the system is in the standby mode.
Cooling Option
Heat Sink with Fan
• “1” and “2” denote the locations of the thermal pads designed to contact
the corresponding components on CH960-CM246/QM370/HM370.
Important:
Remove the plastic covering from the thermal pads prior to mounting the heat sink
onto CH960-CM246/QM370/HM370.
Note:
The system board used in the following illustrations may not resemble the actual
board. These illustrations are for reference only.
Top View of the Heat Sink
Bottom View of the Heat Sink
1
2
