Enable/Disable SATA
Device.
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
SATA And RST Confi guration
SATA Controller(s)
SATA Speed
SATA Mode Selection
Serial ATA Port 0
Port 0
Hot Plug
Serial ATA Port 1
Port 1
Hot Plug
Serial ATA Port 2
Port 2
Hot Plug
Serial ATA Port 3
Port 3
Hot Plug
Serial ATA Port 4
Port 4
Hot Plug
Serial ATA Port 5
Port 5
Hot Plug
[Enabled]
[Auto]
[AHCI]
Empty
[Enabled]
[Disabled]
Empty
[Enabled]
[Disabled]
Empty
[Enabled]
[Disabled]
Empty
[Enabled]
[Disabled]
Empty
[Enabled]
[Disabled]
Empty
[Enabled]
[Disabled]
 Select Screen
 Select Item
Enter: Select
+/
- :
Change Opt.
F1: General Help
F2: Previous Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
SATA Controller(s)
This field is used to enable or disable the Serial ATA controller.
SATA Speed
Select the SATA speed: Auto, Gen1, Gen 2 or Gen3.
SATA Mode Selection
The mode selection determines how the SATA controller(s) operates.
AHCI
This option allows the Serial ATA controller(s) to use AHCI (Advanced Host Controller
Interface).
Intel RST Premium With Intel Optane System Acceleration (for CS630-Q370
only)
This option allows you to create RAID or Intel Rapid Storage configuration with Intel
®
Optane
™
system acceleration on Serial ATA devices.
Serial ATA Port 0/1/2/3/4/5 and Hot Plug
Enable or disable the Serial ATA port and its hot plug function.
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Version 2.20.1271. Copyright (C) 2018 American Megatrends, Inc.
HD Audio Subsystem Confi guration Settings
HD Audio

[Enabled]
 Select Screen
 Select Item
Enter: Select
+/
- :
Change Opt.
F1: General Help
F2: Previous Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
Control Detection of the
HD-Audio device.
Disabled = HDA will be
unconditionally disabled
Enabled = HDA will be
unconditionally enabled.
HD Audio
Control the detection of the HD Audio device.
Disabled
HDA will be unconditionally disabled.
Enabled
HDA will be unconditionally enabled.
