Hardware Installation
31
2.6.7 Game/MIDI Port
The Game/MIDI port is identical to that of a standard PC game
adapter or game I/O port. Connect an analog joystick to the 15-pin
D-sub connector (CN301 - Gold) located at the ATX double deck
ports of the system board. This port works well with any application
that is compatible with the standard PC joystick. You can configure
the game port in the Integrated Peripherals submenu (“Super IO
Device” field) of the BIOS.
Game/MIDI Port
CN301
