Onboard Audio Jacks
The mainboard is equipped with 3 audio jacks. A jack is a one-hole
connecting interface for inserting a plug.
Line-out Jack (Lime - CN3A1)
This jack is used to connect external speakers for audio output from
the mainboard.
Line-in Jack (Light Blue - CN3B1)
This jack can be connected to the line-out jack of any external audio
devices such as Hi-fi set, CD player, AM/FM radio tuner, synthesizer,
etc. Connect a stereo cable from the line-out jack of your external
device to this line-in jack.
Mic-in Jack (Pink - CN3C1)
Connect a microphone to the mic-in jack.
Front Audio (J21)
J21 provides you the option of connecting another line-out and mic-
in jacks.
