DFI PM12-TC - Page 45

2
Hardware Installation
45
Pin
1
2
3
4
5
6
7
8
9
10
Function
3.3V
3.3V
Ground
+5V
Ground
+5V
Ground
PW-OK
5VSB
+12V
Pin
11
12
13
14
15
16
17
18
19
20
Function
3.3V
-12V
Ground
PS-ON
Ground
Ground
Ground
-5V
+5V
+5V
Pin
1
2
3
4
ATX Main Power Connector
Function
Ground
Ground
+12V
+12V
+12V Power Connector
