You need at least 3 modules to operate an 52/XR MADI Router. These modules
are inserted into the DSP Frame I/O layout by default.
·
Slot 1: 52-6710 Sync Module
·
Slot 2: 52-6850 Communication Controller
·
Slot 9: 52-6440 Router Kernel
You are allowed to change the type of the preconfigured router kernel (type
52-6442 supports 2048 channels, type 52-6440 supports 4096 channels), but at
least one routing kernel is necessary for operation.
For each of these preconfigured, essential modules, you can configure a
redundant module into the designated slot of the DSP frame.
Inserting a redundant module into the DSP Frame I/O does not automatically
enable the redundancy for this part of the system. Make sure to insert redundant
hardware into your frame, too.
