Configuring MADI Redundancy
changed
Picture added.
Version 1.5.0:
Chapter / Section
State
Note
52-5310A - MB/XD/XR GPIO Module,
8 out,4 in
added
Pin assignment.
52-5311A - MB/XD/XR GPIO Module,
8 out,4 in
added
Pin assignment.
52-6710A - XR Router/DSP Sync.
Module
added
Pin assignment.
52-6720A - XR True Output
Monitoring
added
Pin assignment.
52-6120A - XR Dual MADI Module,
multimode
added
Meaning of the LEDs.
52-6125A - XR Dual MADI Module,
single mode
added
Meaning of the LEDs.
52-6129A - XR Dual MADI Module,
multi/single
added
Meaning of the LEDs.
52-5310A - MB/XD/XR GPIO Module,
8 out,4 in
added
Meaning of the LEDs.
52-5311A - MB/XD/XR GPIO Module,
8 out,4 in
added
Meaning of the LEDs.
52-6440A - XR Router/DSP Kernel
Module 4096
added
Meaning of the LEDs.
52-6442A - XR Router/DSP Kernel
Module 2048
added
Meaning of the LEDs.
52-6850A - XR Comm. Controller, red.
added
Meaning of the LEDs.
52-6851A - XR Communication
Controller
added
Meaning of the LEDs.
52-6710A - XR Router/DSP Sync.
Module
added
Meaning of the LEDs.
52-6720A - XR True Output
Monitoring
added
Meaning of the LEDs.
