17. ILLUSTRATED PARTS LISTS
DECK ASSEMBLY
Front Cover
Deck
Flat Washer - M12, Zinc
Split Lock Washer - M12, Zinc
Bolt - BHSCS, M12x25, Zinc, 8.8
Deck Underside Cover
Wheel Assembly
Bolt - HHCS Combo, M12x35, Zinc, 8.8
Wheel Bracket
Hairpin - 57mm Length
Wheel - 6", Rubber, Smooth, Incl Bearings
Wheel Axle
Rear Caster Assembly
Bolt - BHSCS, M8x20, Zinc, 8.8
Bolt - BHSCS, M8x25, Zinc, 8.8
Nylock Nut - M8, Zinc
Rear Caster - 3 in.
Pad - Propane Tank Bottom Support
Flat Washer - M8, Zinc
PART NO. DESCRIPTION QTY.
ITEM
1
2
3
4
5
6
7
7.1
7.2
7.3
7.4
7.5
8
8.1
8.2
8.3
8.4
9
10
W10369
W10370
W10371
W10372
W10373
W10374
W10375
W10376
W10377
W10378
W10379
W10380
W10381
W10382
W10383
W10384
W10385
W10386
W10387
1
1
4
4
4
1
2
4
1
1
1
1
2
2
2
4
1
1
4
