17. ILLUSTRATED PARTS LISTS
SHROUD ASSEMBLY
Shroud - 27"
Shroud - 24"
Shroud - 21"
Seal Holder - H Channel, cut to t 1
Kerf Dust Seal - 96 in. length, cut to t
Machine Screw - PPH M4x16
Flat Washer - M4x12
Flat Washer with M4 Threaded Hole
Dust Chute - 27&24 in. Compatible
Dust Chute - 21in. Compatible
Foam Gasket - Dust Chute
Cap - Dust Chute
Flange Bolt - M6x16 Zinc
Nylock Nut - M6, Zinc
PART NO. DESCRIPTION QTY.
ITEM
1
2
3
4
5
6
7
8
9
10
11
W10442
W10443
W10444
W10599
W10547
W10446
W10447
W10448
W10538
W10594
W10597
W10539
W10595
W10596
1
1
1
6
6
6
1
1
1
4
4
FHCS Bolt - M10x75, Zinc, Grade 8.8
Washer - Countersunk Hole
Sleeve Spacer
Flat Washer - 19.5 ID x 30 OD x 2 mm
Compression Spring
PART NO. DESCRIPTION QTY.
ITEM
1
2
3
4
5
W10451
W10450
W10449
W10453
W10452
1
1
1
1
1
