17. ILLUSTRATED PARTS LISTS
FRONT END ASSEMBLY
Bearing Cover
External Shaft Circlip - 30mm
Bearing - 6206-2RZ, 30x62x16 mm
Bolt - HHCS Combo, M12x30, Zinc, 8.8
Bearing Housing
Key - 1/4 x 1/4 x 28mm
Set Screw - M6x12
Shaft - Front End, Hex Drive, Bolt-Lock
Pulley - 7.9 in
PART NO. DESCRIPTION QTY.
ITEM
1
2
3
4
5
6
7
8
9
W10417
W10418
W10419
W10420
W10421
W10422
W10416
W10657
W10424
1
4
2
4
1
1
2
1
1
