17. ILLUSTRATED PARTS LISTS
METAL PAD DRIVER
Flex Plate
Shaft Coupler Hub - Hex Hole, Bolt Lock
Nylock Nut - M8, Zinc
Nylock Nut - M10, Zinc
Flat Washer - M10, Zinc
Hex Flanged Bolt - M8x25, Zinc
Spacer - Flex Plate
27 METAL SPUN DISK
Pad Holder - Female Housing
Nylock Nut - M10, Zinc
Pad Gripper Surface - 27"
Flat Washer - M10, Zinc
Bolt - HHCS M10x55, Short Head, Zinc, Gr 8.8
Pad Holder - Male Threaded Flange
Bolt - HHCS Combo, M12x25, Zinc, 8.8
Rivet 3/16 BLACK. Steel
PART NO. DESCRIPTION QTY.
ITEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
W10425
W10655
W10384
W10367
W10427
W10428
W10429
W5227
W10431
W10367
W10433
W10427
W10436
W10437
W10656
F0162923
1
1
6
6
6
6
6
1
1
6
1
6
6
1
1
8
