16
Til ng Console
To ensure users of every stature can maintain a clear and highly visible view of the console, the 910Ef features a l ng console.
Hinged at the bo om.
To adjust the console, grip the display at the top and l ng the en re console fore and a un l the desired viewing angle is
achieved.
Variable-Width Footbeds
The variable-width footbeds are designed to accommodate the width of an individual’s pelvis. A wider pelvis typically indicates
the body requires a wider stance. The 910Ef allows the user to adjust the width of the footbeds to more closely match their
natural alignment and mechanics.
To adjust the footbeds, remove the six (6) clear plas c footbed caps and set aside. Loosen the six (6) Allen bolts un l the
footbeds moves freely. There is no reason to completely remove the bolts. Align the footbeds to the desired posi on as
indicated by the markings on the footbed liner. Re-fi x the footbeds by ghtening the six (6) Allen bolts. Reinstall the six (6)
footbed caps.
Adjustable-Width Handlebars
The adjustable-width handlebars are designed to accommodate an individual’s body mechanics. Rather than a emp ng to
adjust the user’s natural mo on to one that is fi xed and infl exible, the 910Ef off ers a customized fi t. The three handlebar
posi ons allow the width to be adjusted.
To adjust the bars, open the red quick-release levers on the le and right pivots. Select the desired posi on and reset the
quick release lever. The pressure required to lock the lever should be suffi cient to remove any movement of the handlebar.
Adjustment of the lever is similar to a nut and bolt. Hold the lever in the open posi on and rotate the nut on the opposite end
clockwise to ghten and counter-clockwise to loosen. While holding the handlebar in the desire posi on, close the lever. The
amount of pressure required to properly lock the lever should leave an impression in the palm of the user’s hand.
WORKOUT GUILDLINES
