8
ASSEMBLY INSTRUCTIONS
• Unpack the 910Ef from the carton. Please recycle.
• Assembly will require 2 people.
• Verify the carton contains all parts from the list.
• Install leveling foot (D-40) with lock washer (D-39) under the the
front stabilizer.
• Install and align the Rail Frame (G), using the side bolt and washer.
Make sure all bolts and washers (J-1, & J-3) are aligned and
ghtend properly. Note - A loose bolt could cause misalignment
of the track and cause poor wheel alignment and or a rubbing
sound.
• Tighten the bo om bolts and washers (J-2 & J-1), have one person
lt machine forward, res ng the weight on the stabilizer roller
while the other person installs and ghtens the bo om bolts. Use
CAUTION when preforming this step, use two(2) people!
