Diamondback 910Ef - Installing Drive System Components

910Ef Owner’s Manual
9
ASSEMBLY INSTRUCTIONS
• Install the Step Arms (H-L & H-R) by using the washer (H-15)
and Bolt (H-16). Repeat for opposite side, make sure to  ghten
fi rmly.
• Install the Pedal Arms (I-L & I-R) to the Step Arms (H-L & H-R)
by using the bolts and washers (I-9 & I-8) and install into (I-7)
Footbed bracket. Repeat for opposite side, make sure to  ghten
fi rmly.
