10
ASSEMBLY INSTRUCTIONS
• Remove the Mast Bolts and Washers (D-1, D-2,
D-3 & D-4).
• Connect the Wire Harness Upper (B-1) to Wire
Harness Lower (D-5) taking care to ensure the
connec on is fi rm.
• Pull the wire harness from top of mast upward.
• Slide the upper mast(B) down onto the lower
frame. Use CAUTION and do not pinch wire
harness cable or connector.
• Re-install Mast Bolts and Washers (D-1, D-2, D-3
& D-4) and ghten.
• Assemble the bolt cover over the mast
connec on. Place (B-19) and (B-20) around
mast and fi x screws (B-22) into posi on.
• Place front cover into posi on and instal bolts
(B-21) by hand - note- these bolts do not
require a large amount of force, use cau on
when ghtening into place.
• Install the Pedal Arm (I-l & I-R) into the Lower
Handlebar Pivot and fi x with (I-16) nut, ghten
fi rmly. Then using the allen wrench install the
cover cap (I-17) with the screw (I-18). Then
ghten fi rmly.
Lower Handlebar Pivot
Lower Handlebar Pivot
