Box Spanner
-flat washer 8* 19*2T (2)
-Screws M8*P1.25*16L (4)
-Curved Washer 8* 19*2T (2)
910Ef
Assembly Hardware Kit
DBF Part # 22-22-1806
Allen Wrench Set
Assembly of Technical Items
Assembly of all Diamondback Fitness products should be performed by a Diamondback Fitness Dealer or
Authorized Technician. A signifi cant amount of technical knowledge is required for the safe and complete as-
sembly of the unit. Many retailers will off er delivery and assembly as part of the sales agreement. If this unit
was sold unassembled (in the carton) and you do not feel you can perform the assembly successfully, please
call the dealer for service. Service calls for improper assembly are not covered by the Warranty Policy and
any associated charges will be the responsibility of the owner. Assembly may include adjustment and align-
ment of side cases and a achment brackets as needed for proper func on.
