12


23. Removethefour(4)Philipsscrews(L3)andtheconsole
hingecover(L2)fromthebackoftheconsole(L1)andset
aside.
24. Removethefour(4)Philipsconsolemountingscrews(L6)
frombacksideoftheconsole(L1)andsetaside.
25. Routewireconn
ectorsM1&M2throughbacksideofthe
consolehingecover(L2).
26. Whilesupportingtheconsole(L1),carefullyjoin
connectorsL4withM1.Ensuretheconnectionis
complete.
27. JoinconnectorL5withM2.Applyfirmpressuretoensure
positiveengagement.
28. Tilttheconsolehingeplate(M3)towardtherearofthe
unit.
29. Re
installthefour(4)Philipsmachinescrews(L6)through
theundersideoftheconsolehingeplate(M3)andinto
thebacksideoftheconsole(L1).Onlytheupperand
lowersetsofholesshouldbeused.Donoinstallthe
screwsinthecenterholes.
30. Withtheconsoletiltedupright,alignthehingecover(L2)
withtheappropriateholesinthebacksideoftheconsole.
Reinstallthefour(4)Philipswoodscrews(L3).
31. Placethewaterbottle(P)intheholder.
32. Plugthepoweradapter(Q)intoa120voltoutlet
.Plugthe
otherendintotheinputjack(R).
33. Checkthestabilityoftheunit.Ifrequired,adjustthe
levelingfeettoeliminateanyrockingof theunitwhilein
use.Lockthefeetinplacebytighteningthenu
tupward
(counter‐clockwise)againsttheframe.
