Diamondback 910Er - FINAL INSTALLATION; CUSTOM USER ADJUSTMENTS; Diamondback Natural Alignment (DNA); Variable-Width Footbeds


910ErOwner’sManual

13

FINALINSTALLATION
Uponcompletionofthe assemblysteps,itmaybenecessarytomovetheunit.The910Eris
equippedwithanintegratedtransportwheelwhichisrecessedintothefrontoftheframe.Tomove
theunit,lifttherearframe,usingthehand‐hold.Lifttherearendupwarduntilthewheelstouchthe
floor,andcarefullyrolltheunitintoposition.
Plugtheunitintoapoweroutlet.
Ensuretheunitisstablebyadjustingthelevelingfeet.
CUSTOMUSERADJUSTMENTS‐DiamondbackNaturalAlignment(DNA)
Withthe910Ernowassembledandsetintoplace,theuser‐specificsettingsshouldbeadjusted.DiamondbackFitnessrecognizesthefactthat
eachbodyisunique.Severalbuiltinfeaturesallowtheusertofinetunethefitofthe910Erforamoreergonomicandcomfortableworkout.
WecallthesefeaturesDiamondbackNaturalAlignmentorDNA.
Variable‐WidthFootbeds
Thevariable‐widthfootbedsaredesignedtoaccommodatethewidthof
anindividual’spelvis.Awiderpelvistypicallyindicatesthebodyrequires
awiderstance.The910Erallowstheusertoadjustthewidthofthe
footbedsfrom1.7”(4.3cm)wideto3.2”(8.1cm)tomorecloselymatch
theirnaturalalignmentandmechanics.
Toadjustthefootbeds,removethesix(6)clearplasticfootbedcapsand
setaside.Loosenthesix(6)Allenboltsuntilthefootbedsmovesfreely.Thereisnoreasontocompletely
removethebolts.Alignthefootbedstothedesiredpositionasindicatedbythemarkingsonthefootbed
line
r.
Re‐fixthefootbedsbytighteningthesix(6)Allenbolts.Reinstallthesix(6)footbedcaps .
