Dibo PTL-M - Components; General; Visual Perception

EN COMPONENTS
DiBO 16
Components
GENERAL
Irrespective of the type of high pressure cleaner the cleaner exists from a range
of characteristic machine components which are described below. Thus each
cleaner have its own maximum pressure and maximum flow.
These you can retrieve in the technical data of the machine.
VISUAL PERCEPTION
PTL-M
5
1 fuel filler cap
2 push bar
3 lifting eye
4 high pressure exit
5 fuel engine
6 spay equipment
7 high pressure pump
8 pressure regulating valve
9 strainer
10 water supply
11 pressure gauge
1
2
5
7
3
6
9
10
4
8
11
