OPERATOR’S MANUAL
PM100/PM100E Planter Monitor
11001-1426-200612
TROUBLESHOOTING 15
TROUBLESHOOTING
NOTE: Do not replace fuse with one
having a higher amperage
rating, the console could be
damaged internally.
PROBLEM PROBABLE CAUSE CORRECTIVE ACTION
Unit will not power on.
No LEDs will illuminate
during the power up
sequence.
Loose connection
between power harness
and monitor.
Make sure harness
connection is centered
and fully inserted. Make
sure the power harness
is properly connected to
the monitor.
Bad fuse. Check the fuse in the
power harness near the
battery. If bad, replace
with a 3A AGC fuse.
Make sure the positive
and negative
connections of the power
harness are not
reversed.
Defective power harness
or monitor.
If the fuse is bad again,
the power harness or the
console can be faulty
and require replacement.
Contact your distributor
or DICKEY-john Service
Department at
1-800-637-3302.
Bad battery connection. Check battery
connections and make
sure the connections are
clean and tight.
Low system voltage. Make sure battery
voltage is between 10
and 16 volts DC.
To Next Page
