7.4.2 Single Channel Mode – Automatic Channel Recognition
Your Hagen can automatically recognize the pedal’s send/receive channel. To get your amp into the
mood (or mode) for this, push and hold “Mute” and then activate any program change button on
your MIDI pedal. The amp will look for a program change and recognize the channel it is being sent
on. Then it will switch to this channel and stay there as soon as you let go of “Mute”.
7.4.3 Single Channel Mode – Manual Channel Selection
If you would like to have your Hagen on a certain MIDI channel, then we can accommodate you
here as well. Here is how this works:
Push and hold “Mute” and then turn on the preamp channels in the order that corresponds to your
midi channel preference. For example: if you want to have your Hagen to respond only to MIDI
information that is being sent on channel 7, then you must hold the “Mute” button down and turn
the Preamp channel one selector off, channel two selector on, channel 3 selector on, channel 4
selector off. If you let go of “Mute” now, then your Hagen is set to respond to MIDI channel 7 only.
Get it? The table below gives you the sequence for all 16 MIDI channels.
Midi
Channel
Ch
1
CH
2
CH
3
CH4
1 off off off off
2 on off off off
3 off on off off
4 on on off off
5 off off on off
6 on off on off
7 off on on off
8 on on on off
9 off off off on
10 on off off on
11 off on off on
12 on on off on
13 off off on on
14 on off on on
15 off on on on
16 on on on on
