Digga Remote Switches (Optional)
2 Position Toggle Switch
(DM-000026)
2-Position Toggle Switch
Cable Ties
Excavator Joy SticK
2 Position Floor mounted Switch (DM-000030)
To 2 Speed Controller
(DM-000013)
Connect to
plug on
controller marked
“remote”
Connect to
plug on
controller marked
“remote”
SU PPLY
To Boom
Harness
If using a remote joystick mounted toggle switch part number DM-000026 or
a oor mounted switch part number DM-000030 to select the two speed, then
the rocker switch on the 2 Speed controller, must be positioned in the low
speed position.
13 2 Speed Operating Instructions
REMOTE
OR
