DWL-3000XY & DWL-3500XY Instruction Manual
1
1. DEVICE OVERVIEW
1.1. Technical Specication
DWL-3000XY DWL-3500XY
Measuring Range
0° ~ ±90.00° (Single-Axis)
0° ~ ±15.00° (Dual-Axis)
0° ~ ±20.000° (Single-Axis)
0° ~ ±10.000° (Dual-Axis)
Resolution & Repeatability 0.01° (175μm/M) (0.002 in/Ft) 0.001° (18μm/M) (0.0002 in/Ft)
Accuracy
± 0.01° at 0° to 10.00°
± 0.03° at other angles
± 0.001° at 0° to 2.000°
± 0.003° at other angles
Display Color TFT LCD
Power Supply* 4 x AAA 1.5V Batteries / USB
Connectivity
USB 2.0 Cable (≤ 5 metre)
Bluetooth (≤30 metre) (Optional)
Material PC ABS / Aluminium PC ABS / Alloy Steel
Operating Temperature 10°F to 120°F or -10°C to +50°C (Calibrated for the entire temperature range)
Dimension 188mm x 62mm x 37mm
Weight (Approx.) 580g 1100g
Cross Axis Error Negligible (± 0.0025°) Negligible (± 0.00025°)
PC SYNC Software
Basic Edition
Professional Edition (Optional)
Vibrometer 2.0g
User Self Calibration Yes
Table 1. Technical specication of DWL3000XY & DWL3500XY
Notes:
- Product specication and appearance are subject to change for product improvement without prior notice.
- *Alternative power can be obtained from External USB Power Source.
- Product performance to specication complies with accredited Calibration & Test Providers in USA, Japan, UK,
and Germany to conform with NIST, JIS, UKAS & DIN under the International Laboratory Accreditation Cooperation
(ILAC) and American Association for Laboratory Accreditation (A2LA). For more information, please visit “www.
digipas.com”.
