Print Format
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
4.4 Programming of Free Format
M o d e l S M - 5 3 00 O p e r a t i o n M a n u a l | 162
OPERATION
DISPLAY
11.
Touch [DISPLAY] tab to view the
programmed screen.
Note: Adjust the position of Commodity Name
if necessary.
12.
Touch [FIELDS] tab and select the item
data of Ingredients.
Note:
1. Touch [ARROW DOWN] or [ARROW
UP] for more selection.
2. Touch [SORT BY NAME] or [SORT BY
ID] for more selection
3. To save data, touch [DISPLAY] folder
and touch [SAVE] key.
4. Touch Option Button to be short cut to
shown desired FIELDS.
13.
Touch [X AXIS] key and enter the value by
keypad. (e.g. 8)
14.
Touch [Y AXIS] key and enter the value by
keypad. (e.g. 21)
