Digigram VX222e - Specifications; Configuration Details; Input Specifications

VX222e & VX222e-Mic
User Manual
15
SPECIFICATIONS
Configuration
VX222e VX222e-Mic
Bus/Format
PCI EXPRESS
TM
(PCIe
®
) x1
(x2, x4, x8, x16, x32 compatible)
Digital Signal Processor Motorola 56303 at 100 MHz
RAM 128 kWords 512 kWords
Size 168 mm x 99 mm x 20 mm
Power requirements
(+3.3V/ +12V)
1 A / 0.2 A
1.3 A
∗
/ 0,22 A
Operating:
temp / humidity
(non-condensing)
0°C / +50°C • 5% / 90%
Storage: temp / humidity
(non-condensing)
-5°C / +70°C • 0% / 95%
Inputs
VX222e VX222e-Mic
Analog line inputs (mono)
2 balanced
∗∗
2 balanced
∗∗
Maximum input
level/impedance
+24 dBu / <10 kΩ +24 dBu / >10 kΩ
Digital inputs (stereo)
1 AES/EBU
∗∗∗
cf. separate table
Programmable input gain
analog: from –94 dB to +16 dB
⊗
digital: from –110 dB to +18 dB
Other inputs
2 GPI (dry contact),
LTC
AES11 synchronization Yes
∗
enabling phantom power (48 V) may increase this value by 50%
using the 10 V AES42 power to feed the microphone may increase this value by 90%
∗∗
can be used with unbalanced signals
∗∗∗
can be used as S/PDIF interface as well
⊗
maximum sensitivity: 0 dBFs for –16 dBu input
