18
Analog mono microphone input features
VX222e-Mic
Power supply switchable 48 V phantom power
Programmable mic gain 0 to 66 dB in 0.5 dB steps
Maximum input
level/impedance
+10 dBu / >10 kΩ
Equivalent Input Noise,
A/D-D/A at 48kHz, G=60 dB
<-125 dBu
Programmable noise-gate
threshold
-52 dB, -42 dB, -32 dB
Programmable
compressor/limiter threshold
from –26 dB to 0 dB
Programmable compressor ratio
1, 1.2, 1.5, 1.8, 2, 2.5, 3, 3.5, 4, 4.5
Programmable
compressor/limiter gain
from 0 to 16 dB
Limiter ratio
15:1
Compressor/limiter release time 150 ms
Management of line and mic
inputs
Mixed together before A/D, with independent
level and mute controls
AES42 microphone input features - VX222e-Mic
Power supply 10 V min / 250 mA max
Remote control Yes
Supported synchronization
Operational mode 1
(the microphone generates its own clock)
