Digigram VX222e - Additional VX222 e-Mic Inputs; Output Specifications; Connector Descriptions

16
Additional inputs VX222e-Mic
Microphone input
1 professional mono with
- high-quality preamplifier
- switchable 48 V phantom power
- analog expander/compressor/limiter
This input is mixed with the two line inputs before
A/D conversion.
Digital input (stereo)
∗
1 AES/EBU, AES42 compatible
- with hardware sample rate converter (SRC)
- supplying 10 V to feed a digital microphone
- allowing remote microphone control
Other inputs
∗∗
AES/EBU Sync (up to 200 kHz)
Outputs
VX222e VX222e-Mic
Analog line outputs (mono)
2 servo-balanced
∗∗∗
Maximum output level /
impedance
+24 dBu / < 100 Ω
Digital outputs (stereo) 1 AES/EBU, up to 200 kHz
Programmable output gain
analog: from –24 dB to +24 dB
digital: from –110 dB à +18 dB
Other outputs
1 stereo headphone output (600 Ω)
2 GPO (relay, 0.5 A, 48 VCC)
Connectors
VX222e VX222e-Mic
Internal connector Inter board synchronization
External connectors
• 15-pin Sub-D for analog I/Os
• 15-pin HD Sub-D for digital I/Os, Sync.,
and GPIO
• Mini jack headphone stereo output
(3,5 mm TRS female jack)
∗
Hardware sample rate converter available on VX222e on special request
∗∗
AES/EBU sync input available on VX222e on special request
∗∗∗
electronically servo-balanced outputs provide automatic level adjustment to accommodate
either balanced or unbalanced lines
