33
REMOTE CONTROL
Operating Distance 10 m Max.
Batteries 2x1.5V Micro (R-03/AAA)
TUNERS
2 xRF In
IEC-type, female (75Ohm)
2 x RF Out (loop through) IEC-type, male (75Ohm)
HARD DISK
Hard Disk capacity 80 GB
FRONT PANEL
Display VFD
Remote Control Keys
Standby ON/OFF, Menu, Record, Pause, OK,
Menu Up/Down, Menu Left/Right.
AUDIO R / L
Connector 2 x RCA (R + L)
Output 2 Vrms, 0 dBfs / Z = 10 kohm
DIGITAL AUDIO
Output Optical SPDIF
A / V & DATA IN / OUT
Scart TV scart, AUX scart
RGB Video Output TV scart
RGB Video Intput AUX scart
CVBS Video Output TV scart, AUX scart
CVBS Video Input AUX scart
Analog Audio Output TV scart, RCA jack, AUX scart
Analog Audio Input AUX scart
Digital Audio Output Optical output
Data Interface RS232 (max 115200 bps),9Pin
* Any changes in the Instruction Manual format is reserved.
